 The
model 43AL is a 1/32 DIN size, 3 1/2 digit, DC current input
digital panel meter. It taps its operating power from a
4-20 mA input signal, so it is just as simple as inserting
the meter into any section of the current loop to monitor
the signal. This is especially beneficial in locations where
no power source is available, such as a remote outdoor site
(e.g. tank yard).
The 10.16 mm high LED is highly legible even without auxiliary
power source.
The display
range can be scaled to represent engineering units such
as temperature, level and flow volume: the zero offset can
be adjusted within ±200, the full-scale range can
be adjusted within 100 and 1999 with movable decimal point
positions.
The 43AL
conforms to the EU's EMC Directive and is approved by UL
for non-hazardous locations.
The model
6BX-E Outdoor Enclosure is available for installing the
443AL outside. A dedicated mounting bracket assembly is
optional to mount it on a 2-inch pipe.
|
|
43AL SPECIFICATIONS
|
| LED |
10.16 mm (.4") ,
7-segment, red |
| Number of display digits
|
3 1/2 |
| Maximum display range |
1999 |
| Scaling, Zero |
±200 counts |
| Scaling, Span |
100 to 1999 counts |
| Decimal point position
|
3 positions selectable with internal
DIP SW behind the cover |
| Input signal |
4-20 mAdc |
| Voltage drop at 4 mA |
5.0 V |
| Voltage drop at 20 mA |
5.3 V |
| Environmental protection |
IP 20 |
| Safety approval |
UL |
| Conformed CE directive |
EMC |
|
6BX-E SPECIFICATIONS
|
| Environmental protection
|
IP 65, NEMA 4X |
| Safety approval |
N/A |
|
 The
standard die-cast aluminum case, coated with epoxy resin,
which has resistance against corrosion or heat, is suitable
not only for normal environments but also hard environments
such as coastal areas. For harsher environments, a stainless
steel case is optional. Both types of enclosures have excellent
environmental protection equivalent to IP 65 and NEMA 4X.
Though the 43AL with the 6BX-E is not approved for explosive
locations, its protection is more than enough for use in
most other locations.
When installing the
43AL inside the 6BX-E, the Adaptor Plate A-35 is convenient.
The plate can be shipped with a terminal block to facilitate
the input wiring to the 43AL.
